CÓDIGOS Y MEDIDAS DE LOS CALIBRES PARA EL CONTROL DE ROSCAS PETROLERAS

by admin_retusin| | CALIBRES, ANILLOS Y TAPONES

CÓDIGOS Y MEDIDAS DE LOS CALIBRES PARA EL CONTROL DE ROSCAS PETROLERAS

Se detallan los diferentes tipos de roscas con sus medidas y pasos según norma. Así también los códigos utilizados para una correcta identificación. Todas estas líneas se producen de forma completa en nuestra planta industrial.

ROSCAS PETROLERAS
ANILLOS – LINE PIPE – API 5B
10170000LP 1/8 x 27 API 5B
810170005LP 1/4 x 18 API 5B
810170010LP 3/8 x 18 API 5B
810170015LP 1/2 x 14 API 5B
810170020LP 3/4 x 14 API 5B
810170025LP 1 x 11 1/2 API 5B
810170030LP 1 1/4 x 11 1/2 API 5B
810170035LP 1 1/2 x 11 1/2 API 5B
810170040LP 2 x 11 1/2 API 5B
810170045LP 2 1/2 x 8 API 5B
810170050LP 3 x 8 API 5B
810170055LP 3 1/2 x 8 API 5B
810170060LP 4 x 8 API 5B
810170065LP 5 x 8 API 5B
810170070LP 6 x 8 API 5B
ROSCAS PETROLERAS
ANILLOS CASING LONG & SHORT – API 5B
810170075CSG 4 1/2 x 8 API 5B LONG AND SHORT
810170080CSG 5 x 8 API 5B LONG AND SHORT
810170085CSG 5 1/2 x 8 API 5B LONG AND SHORT
810170090CSG 6 5/8 x 8 API 5B LONG AND SHORT
810170095CSG 7 x 8 API 5B LONG AND SHORT
ROSCAS PETROLERAS
ANILLOS – BUTTRESS CASING – API 5B
810170100BUTTRESS CASING 4 1/2 x 5 API 5B
810170105BUTTRESS CASING 5 x 5 API 5B
810170110BUTTRESS CASING 5 1/2 x 5 API 5B
810170115BUTTRESS CASING 6 5/8 x 5 API 5B
ROSCAS PETROLERAS
ANILLOS – NON UPSET TUBING – API 5B
810170120TBG 1.050 x 10 API 5B NON UPSET TUBING
810170125TBG 1.315 x 10 API 5B NON UPSET TUBING
810170130TBG 1.660 x 10 API 5B NON UPSET TUBING
810170135TBG 1.900 x 10 API 5B NON UPSET TUBING
810170140TBG 2 3/8 x 10 API 5B NON UPSET TUBING
810170145TBG 2 7/8 x 10 API 5B NON UPSET TUBING
810170150TBG 3 1/2 x 10 API 5B NON UPSET TUBING
810170155TBG 4 x 8 API 5B NON UPSET TUBING
810170160TBG 4 1/2 x 8 API 5B NON UPSET TUBING
ROSCAS PETROLERAS
ANILLOS – EXTERNAL UPSET TUBING – API 5B
810170165UPTBG 1.050 x 10 API 5B EXTERNAL UPSET TUBING
810170170UPTBG 1.315 x 10 API 5B EXTERNAL UPSET TUBING
810170175UPTBG 1.660 x 10 API 5B EXTERNAL UPSET TUBING
810170180UPTBG 1.900 x 10 API 5B EXTERNAL UPSET TUBING
810170185UPTBG 2 3/8 x 8 API 5B EXTERNAL UPSET TUBING
810170190UPTBG 2 7/8 x 8 API 5B EXTERNAL UPSET TUBING
810170195UPTBG 3 1/2 x 8 API 5B EXTERNAL UPSET TUBING
810170200UPTBG 4 x 8 API 5B EXTERNAL UPSET TUBING
810170205UPTBG 4 1/2 x 8 API 5B EXTERNAL UPSET TUBING
ROSCAS PETROLERAS
ANILLOS – INTEGRAL JOINT – API 5B
810170210IJ 1.315 x 10 API 5B INTEGRAL JOINT TUBING
810170215IJ 1.660 x 10 API 5B INTEGRAL JOINT TUBING
810170220IJ 1.900 x 10 API 5B INTEGRAL JOINT TUBING
810170225IJ 2.063 x 10 API 5B INTEGRAL JOINT TUBING
ROSCAS PETROLERAS
ANILLOS – REGULAR – API SPEC 7
810170230REG 1 x 6 API SPEC 7 REGULAR
810170235REG 1 1/2 x 6 API SPEC 7 REGULAR
810170240REG 2 3/8 x 5 API SPEC 7 REGULAR
810170245REG 2 7/8 x 5 API SPEC 7 REGULAR
810170250REG 3 1/2 x 5 API SPEC 7 REGULAR
810170255REG 4 1/2 x 5 API SPEC 7 REGULAR
810170260REG 5 1/2 x 4 API SPEC 7 REGULAR
810170265REG 6 5/8 x 4 API SPEC 7 REGULAR
ROSCAS PETROLERAS
ANILLOS – FULL HOLE – API SPEC 7
810170270FH 3 1/2 x 5 API SPEC 7 FULL HOLE
810170275FH 4 x 4 API SPEC 7 FULL HOLE (NC40)
810170280FH 4 1/2 x 5 API SPEC 7 FULL HOLE
ROSCAS PETROLERAS
ANILLOS – INTERNAL FLUSH – API SPEC 7
810170285IF 2 3/8 x 4 API SPEC 7 INTERNAL FLUSH (NC26)
810170290IF 2 7/8 x 4 API SPEC 7 INTERNAL FLUSH (NC31)
810170295IF 3 1/2 x 4 API SPEC 7 INTERNAL FLUSH (NC38)
810170300IF 4 x 4 API SPEC 7 INTERNAL FLUSH (NC46)
810170305IF 4 1/2 x 4 API SPEC 7 INTERNAL FLUSH (NC50)
810170310IF 5 1/2 x 4 API SPEC 7 INTERNAL FLUSH
ROSCAS PETROLERAS
ANILLOS – SUKER & POLISHED ROD – API 11B
810170315P2 1/2 x 10 PASA API 11B POLISHED ROD
810170320P4 1/2 x 10 CONTROL DE CONO API 11B POLISHED ROD
810170325P6 1/2 x 10 NO PASA API 11B SUKER Y POLISHED ROD
810170330P8 1/2 x 10 PASA API 11B SUKER ROD
810170335B1 1/2 x 10 REF P/TAPON B2 API 11B SUKER Y POLISHED ROD
810170340B5 1/2 x 10 REF P/TAPON B6 API 11B SUKER Y POLISHED ROD
810170345P2 5/8 x 10 PASA API 11B POLISHED ROD
810170350P4 5/8 x 10 CONTROL DE CONO API 11B POLISHED ROD
810170355P6 5/8 x 10 NO PASA API 11B SUKER Y POLISHED ROD
810170360P8 5/8 x 10 PASA API 11B SUKER ROD
810170365B1 5/8 x 10 REF P/TAPON B2 API 11B SUKER Y POLISHED ROD
810170370B5 5/8 x 10 REF P/TAPON B6 API 11B SUKER Y POLISHED ROD
810170375P2 3/4 x 10 PASA API 11B POLISHED ROD
810170380P4 3/4 x 10 CONTROL DE CONO API 11B POLISHED ROD
810170385P6 3/4 x 10 NO PASA API 11B SUKER Y POLISHED ROD
810170390P8 3/4 x 10 PASA API 11B SUKER ROD
810170395B1 3/4 x 10 REF P/TAPON B2 API 11B SUKER Y POLISHED ROD
810170400B5 3/4 x 10 REF P/TAPON B6 API 11B SUKER Y POLISHED ROD
810170405P2 7/8 x 10 PASA API 11B POLISHED ROD
810170410P4 7/8 x 10 CONTROL DE CONO API 11B POLISHED ROD
810170415P6 7/8 x 10 NO PASA API 11B SUKER Y POLISHED ROD
810170420P8 7/8 x 10 PASA API 11B SUKER ROD
810170425B1 7/8 x 10 REF P/TAPON B2 API 11B SUKER Y POLISHED ROD
810170430B5 7/8 x 10 REF P/TAPON B6 API 11B SUKER Y POLISHED ROD
810170435P2 1 x 10 PASA API 11B POLISHED ROD
810170440P4 1 x 10 CONTROL DE CONO API 11B POLISHED ROD
810170445P6 1 x 10 NO PASA API 11B SUKER Y POLISHED ROD
810170450P8 1 x 10 PASA API 11B SUKER ROD
810170455B1 1 x 10 REF P/TAPON B2 API 11B SUKER Y POLISHED ROD
810170460B5 1 x 10 REF P/TAPON B6 API 11B SUKER Y POLISHED ROD
810170465P2 1 1/8 x 10 PASA API 11B POLISHED ROD
810170470P4 1 1/8 x 10 CONTROL DE CONO API 11B POLISHED ROD
810170475P6 1 1/8 x 10 NO PASA API 11B SUKER Y POLISHED ROD
810170480P8 1 1/8 x 10 PASA API 11B SUKER ROD
810170485B1 1 1/8 x 10 REF P/TAPON B2 API 11B SUKER Y POLISHED ROD
810170490B5 1 1/8 x 10 REF P/TAPON B6 API 11B SUKER Y POLISHED ROD
ROSCAS PETROLERAS
ANILLOS – PAC
810170495PAC 2 3/8 x 4
810170500PAC 2 7/8 x 4
810170505PAC 3 1/2 x 4
ROSCAS PETROLERAS
ANILLOS – SHARP VEE
810170510SHARP VEE 1.900 x 11 1/2
ROSCAS PETROLERAS
ANILLOS – SEC
810170515SEC 2 3/8 x 8
810170520SEC 2 7/8 x 6
810170525SEC 3 1/2 x 6
810170530SEC 4 1/2 x 6
ROSCAS PETROLERAS
ANILLOS – HUGHES SLIM LINE
810170535H 90 - 2 3/8 x 3 HUGHES SLIM LINE
810170540H 90 - 2 7/8 x 3 HUGHES SLIM LINE
810170545H 90 - 3 1/2 x 3 HUGHES SLIM LINE
ROSCAS PETROLERAS
ANILLOS – MACARONI TUBING
810170550MT 3/4 x 6 MACARONI TUBING
810170555MT 1 x 6 MACARONI TUBING
810170560MT 1 1/4 x 6 MACARONI TUBING
810170565MT 1 1/2 x 6 MACARONI TUBING
810170570MT 2 1/16 x 6 MACARONI TUBING
