CÓDIGOS Y MEDIDAS DE LOS CALIBRES PARA EL CONTROL DE ROSCAS PETROLERAS

Se detallan los diferentes tipos de roscas con sus medidas y pasos según norma.
Así también los códigos utilizados para una correcta identificación.
Todas estas líneas se producen de forma completa en nuestra planta industrial.

ROSCAS PETROLERAS
TAPONES - LINE PIPE - API 5B
7101600000LP 1/8 x 27 API 5B
7101600050LP 1/4 x 18 API 5B
7101600100LP 3/8 x 18 API 5B
7101600150LP 1/2 x 14 API 5B
7101600200LP 3/4 x 14 API 5B
7101600250LP 1 x 11 1/2 API 5B
7101600300LP 1 1/4 x 11 1/2 API 5B
7101600350LP 1 1/2 x 11 1/2 API 5B
7101600400LP 2 x 11 1/2 API 5B
7101600450LP 2 1/2 x 8 API 5B
7101600500LP 3 x 8 API 5B
7101600550LP 3 1/2 x 8 API 5B
7101600600LP 4 x 8 API 5B
7101600650LP 5 x 8 API 5B
7101600700LP 6 x 8 API 5B
ROSCAS PETROLERAS
TAPONES - CASING SHORT & LONG – API 5B
7101600750CSG 4 1/2 x 8 API 5B LONG AND SHORT
7101600800CSG 5 x 8 API 5B LONG AND SHORT
7101600850CSG 5 1/2 x 8 API 5B LONG AND SHORT
7101600900CSG 6 5/8 x 8 API 5B LONG AND SHORT
7101600950CSG 7 x 8 API 5B LONG AND SHORT
ROSCAS PETROLERAS
TAPONES - BUTTRESS CASING – API 5B
7101601000BUTTRESS CASING 4 1/2 x 5 API 5B
7101601050BUTTRESS CASING 5 x 5 API 5B
7101601100BUTTRESS CASING 5 1/2 x 5 API 5B
7101601150BUTTRESS CASING 6 5/8 x 5 API 5B
ROSCAS PETROLERAS
TAPONES - NON UPSET TUBING – API 5B
7101601200TBG 1.050 x 10 API 5B NON UPSET TUBING
7101601250TBG 1.315 x 10 API 5B NON UPSET TUBING
7101601300TBG 1.660 x 10 API 5B NON UPSET TUBING
7101601350TBG 1.900 x 10 API 5B NON UPSET TUBING
7101601400TBG 2 3/8 x 10 API 5B NON UPSET TUBING
7101601450TBG 2 7/8 x 10 API 5B NON UPSET TUBING
7101601500TBG 3 1/2 x 8 API 5B NON UPSET TUBING
7101601550TBG 4 x 8 API 5B NON UPSET TUBING
7101601600TBG 4 1/2 x 8 API 5B NON UPSET TUBING
ROSCAS PETROLERAS
TAPONES – EXTERNAL UPSET TUBING – API 5B
710160105UPTBG 1.050 x 10 API 5B EXTERNAL UPSET TUBING
710160170UPTBG 1.315 x 10 API 5B EXTERNAL UPSET TUBING
710160175UPTBG 1.660 x 10 API 5B EXTERNAL UPSET TUBING
710160180UPTBG 1.900 x 10 API 5B EXTERNAL UPSET TUBING
710160185UPTBG 2 3/8 x 8 API 5B EXTERNAL UPSET TUBING
710160190UPTBG 2 7/8 x 8 API 5B EXTERNAL UPSET TUBING
710160195UPTBG 3 1/2 x 8 API 5B EXTERNAL UPSET TUBING
710160200UPTBG 4 x 8 API 5B EXTERNAL UPSET TUBING
710160205UPTBG 4 1/2 x 8 API 5B EXTERNAL UPSET TUBING
ROSCAS PETROLERAS
TAPONES – INTEGRAL JOINT TUBING – API 5B
710160210IJ 1.315 x 10 API 5B INTEGRAL JOINT TUBING
710160215IJ 1.660 x 10 API 5B INTEGRAL JOINT TUBING
710160220IJ 1.900 x 10 API 5B INTEGRAL JOINT TUBING
710160225IJ 2.063 x 10 API 5B INTEGRAL JOINT TUBING
ROSCAS PETROLERAS
TAPONES – REGULAR – API SPEC 7
710160230REG 1 x 6 API SPEC 7 REGULAR
710160235REG 1 1/2 x 6 API SPEC 7 REGULAR
710160240REG 2 3/8 x 5 API SPEC 7 REGULAR
710160245REG 2 7/8 x 5 API SPEC 7 REGULAR
710160250REG 3 1/2 x 5 API SPEC 7 REGULAR
710160255REG 4 1/2 x 5 API SPEC 7 REGULAR
710160260REG 5 1/2 x 4 API SPEC 7 REGULAR
710160265REG 6 5/8 x 4 API SPEC 7 REGULAR
ROSCAS PETROLERAS
TAPONES – FULL HOLE – API SPEC 7
710160270FH 3 1/2 x 5 API SPEC 7 FULL HOLE
710160275FH 4 x 4 API SPEC 7 FULL HOLE (NC40)
710160280FH 4 1/2 x 5 API SPEC 7 FULL HOLE
ROSCAS PETROLERAS
TAPONES – INTERNAL FLUSH – API SPEC 7
710160285IF 2 3/8 x 4 API SPEC 7 INTERNAL FLUSH (NC26)
710160290IF 2 7/8 x 4 API SPEC 7 INTERNAL FLUSH (NC31)
710160295IF 3 1/2 x 4 API SPEC 7 INTERNAL FLUSH (NC38)
710160300IF 4 x 4 API SPEC 7 INTERNAL FLUSH (NC46)
710160305IF 4 1/2 x 4 API SPEC 7 INTERNAL FLUSH (NC50)
710160310IF 5 1/2 x 4 API SPEC 7 INTERNAL FLUSH
ROSCAS PETROLERAS
TAPONES Y REFERENCIAS – SUKER ROD & POLISHED ROD – API 11B
710160315B2 1/2 x 10 PASA API 11B SUKER Y POLISHED ROD
710160320B6 1/2 x 10 NO PASA API 11B SUKER Y POLISHED ROD
710160325P1 1/2 x 10 REF AN P2 API 11B POLISHED ROD
710160330P3 1/2 x 10 REF AN P4 API 11B POLISHED ROD
710160335P5 1/2 x 10 REF AN P6 API 11B SUKER Y POLISHED ROD
710160340P7 1/2 x 10 REF AN P8 API 11B POLISHED ROD
710160345B2 5/8 x 10 PASA API 11B SUKER Y POLISHED ROD
710160350B6 5/8 x 10 NO PASA API 11B SUKER Y POLISHED ROD
710160355P1 5/8 x 10 REF AN P2 API 11B POLISHED ROD
710160360P3 5/8 x 10 REF AN P4 API 11B POLISHED ROD
710160365P5 5/8 x 10 REF AN P6 API 11B SUKER Y POLISHED ROD
710160370P7 5/8 x 10 REF AN P8 API 11B POLISHED ROD
710160375B2 3/4 x 10 PASA API 11B SUKER Y POLISHED ROD
710160380B6 3/4 x 10 NO PASA API 11B SUKER Y POLISHED ROD
710160385P1 3/4 x 10 REF AN P2 API 11B POLISHED ROD
710160390P3 3/4 x 10 REF AN P4 API 11B POLISHED ROD
710160395P5 3/4 x 10 REF AN P6 API 11B SUKER Y POLISHED ROD
710160400P7 3/4 x 10 REF AN P8 API 11B POLISHED ROD
710160405B2 7/8 x 10 PASA API 11B SUKER Y POLISHED ROD
710160410B6 7/8 x 10 NO PASA API 11B SUKER Y POLISHED ROD
710160415P1 7/8 x 10 REF AN P2 API 11B POLISHED ROD
710160420P3 7/8 x 10 REF AN P4 API 11B POLISHED ROD
710160425P5 7/8 x 10 REF AN P6 API 11B SUKER Y POLISHED ROD
710160430P7 7/8 x 10 REF AN P8 API 11B POLISHED ROD
710160435B2 1 x 10 PASA API 11B SUKER Y POLISHED ROD
710160440B6 1 x 10 NO PASA API 11B SUKER Y POLISHED ROD
710160445P1 1 x 10 REF AN P2 API 11B POLISHED ROD
710160450P3 1 x 10 REF AN P4 API 11B POLISHED ROD
710160455P5 1 x 10 REF AN P6 API 11B SUKER Y POLISHED ROD
710160460P7 1 x 10 REF AN P8 API 11B POLISHED ROD
710160465B2 1 1/8 x 10 PASA API 11B SUKER Y POLISHED ROD
710160470B6 1 1/8 x 10 NO PASA API 11B SUKER Y POLISHED ROD
710160475P1 1 1/8 x 10 REF AN P2 API 11B POLISHED ROD
710160480P3 1 1/8 x 10 REF AN P4 API 11B POLISHED ROD
710160485P5 1 1/8 x 10 REF AN P6 API 11B SUKER Y POLISHED ROD
710160490P7 1 1/8 x 10 REF AN P8 API 11B POLISHED ROD
ROSCAS PETROLERAS
TAPONES – PAC
710160495PAC 2 3/8 x 4
710160500PAC 2 7/8 x 4
710160505PAC 3 1/2 x 4
ROSCAS PETROLERAS
TAPONES – SHARP VEE
710160510SHARP VEE 1.900 x 11 1/2
ROSCAS PETROLERAS
TAPONES – SEC
710160515SEC 2 3/8 x 8
710160520SEC 2 7/8 x 6
710160525SEC 3 1/2 x 6
710160530SEC 4 1/2 x 6
ROSCAS PETROLERAS
TAPONES – HUGHES SLIM LINE
710160535H 90 - 2 3/8 x 3 HUGHES SLIM LINE
710160540H 90 - 2 7/8 x 3 HUGHES SLIM LINE
710160545H 90 - 3 1/2 x 3 HUGHES SLIM LINE
ROSCAS PETROLERAS
TAPONES – MACARONI TUBING
710160550MT 3/4 x 6 MACARONI TUBING
710160555MT 1 x 6 MACARONI TUBING
710160560MT 1 1/16 x 6 MACARONI TUBING
710160565MT 1 1/2 x 6 MACARONI TUBING
710160570MT 2 1/16 x 6 MACARONI TUBING
